NPort 5100A Series Introduction
1-3
Product Specifications
Ethernet Interface
Number of Ports:
1
Speed:
10/100 Mbps, auto MDI/MDIX
Connector:
8-pin RJ45
Magnetic Isolation Protection:
1.5 KV built-in
Serial Interface
Number of Ports:
1
Serial Standards:
NPort 5110A: RS
-232
NPort 5130A: RS
-422/485
NPort 5150A: RS
-232/422/485
Connector:
DB9 male
Serial Line Protection:
15 KV ESD protection for all signals, Level 1 Surge, EN61000-4-5
RS
-485 Data Direction Control: ADDC® (automatic data direction control)
Pull High/Low Resistor for RS
-485: 1 KΩ, 150 KΩ
Serial Communication Parameters
Data Bits:
5, 6, 7, 8
Stop Bits:
1, 1.5, 2
Parity:
None, Even, Odd, Space, Mark
Flow Control:
RTS/CTS and DTR/DSR (RS-232 only), XON/XOFF
Baudrate:
50 bps to 921.6 Kbps
Serial Signals
RS
-232: TxD, RxD, RTS, CTS, DTR, DSR, DCD, GND
RS
-422: Tx+, Tx-, Rx+, Rx-, GND
RS
-485-4w: Tx+, Tx-, Rx+, Rx-, GND
RS
-485-2w: Data+, Data-, GND
Software
Network Protocols:
ICMP, IP, TCP, UDP, DHCP, BOOTP, Telnet, DNS, SNMP V1, HTTP, SMTP, IGMP V1/2
Configuration Options:
Web Console (with new Quick Setup), Serial Console (NPort 5110A/5150A only),
Telnet Console, Windows Utility
Windows Real COM Drivers:
Windows 95/98/ME/NT/2000, Windows XP/2003/Vista/2008/7/8 x86/x64,
2012 x64
Fixed TTY Drivers:
SCO Unix, SCO OpenServer, UnixWare 7, UnixWare 2.1, SVR 4.2, QNX 4.25, QNX 6,
Solaris 10, FreeBSD, AIX 5.x, HP
-UX 11i, Mac 10.3
Linux Real TTY Drivers:
Linux kernel 2.4.x, 2.6.x, 3.x
Physical Characteristics
Housing:
Metal
Weight:
340 g
Dimensions:
Without ears: 52 x 80 x 22 mm (2.05 x 3.15 x 0.87 in)
With ears: 75.2 x 80 x 22 mm (2.96 x 3.15 x 0.87 in)
Environmental Limits
Operating Temperature:
Standard Models: 0 to
60°C (32 to 140°F)
Wide Temp. Models:
-40 to 75°C (-40 to 167°F)
Storage Temperature:
-40 to 75°C (-40 to 167°F)
Ambient Relative Humidity:
5 to 95% (non-condensing)
