NPort 5100A Series Initial IP Address Configuration
3-4
Telnet Console
Depending on how your computer and network are configured, you may find it convenient to use network
access to set up your NPort 5100A’s IP address. This can be done using Telnet.
1. From the Windows desktop, click Start and then select Run.
2. Type telnet 192.168.127.254 (use the correct IP address if different from the default) in the Open text
input box, and then click OK.
3. When the Telnet window opens, if you are prompted to input the Console password, input the password
and then press Enter. Note that this page will only appear if the NPort 5100A is password protected.
4. Type 2 to select Network settings, and then press Enter.
5. Type 1 to select IP address and then press Enter.
