NPort 5100A Series Web Console Configuration
DCD changed
The DCD (Data Carrier Detect) signal has changed, also indicating that the modem connection status has
changed. For example, a DCD change to high also means “Connected” between local modem and remote
modem. If the DCD signal changes to low, it also means that the connection line is down.
When the DCD changes, the NPort 5110A/5150A/P5150A will immediately send an e-mail or send an SNMP
trap.
DSR changed
The DSR (Data Set Ready) signal has changed, also indicating that the data communication equipment’s power
is off. For example, a DSR change to high also means that the DCE is powered ON. If the DSR signal changes
to low, it also means that the DCE is powered off.
When the DSR changes, the NPort 5110A/5150A/P5150A will immediately send an e-mail or send an SNMP
trap.
Mail
Setting Factory Default Necessity
Enable, Disable Disable Optional
This feature helps the administrator manage how the NPort 5100A sends e-mail to pre-defined e-mail boxes
when the enabled events—such as Cold start, Warm start, Authentication failure, etc.—occur. To configure this
feature, click the Event Type Mail checkbox.
Trap
Setting Factory Default Necessity
Enable, Disable Disable Optional
This feature helps the administrator manage how the NPort 5100A sends SNMP Trap to a pre-defined SNMP
Trap server when the enabled events—such as Cold start, Warm start, Authentication failure, etc.—occur. To
configure this feature, click the Event Type Trap checkbox.
Upgrade Firmware
Keep your NPort 5100A up to date with the latest firmware from Moxa. Occasionally, compare your NPort
firmware to the version currently available at the Moxa website (www.moxa.com
). If a new firmware version is
available, you can download it and click Import to upgrade your firmware.
