NPort 5100A Series Initial IP Address Configuration
5. From the Property window’s Terminal page, select ANSI or VT100 for Terminal Type and then click OK.
If you select Dumb Terminal as the terminal type, some of the console functions—especially the “Monitor”
function—may not work properly.
6. Press the “ ` ” key continuously and then power on the NPort 5100A.
7. The NPort 5100A will receive the “ ` ” string continuously and then auto switch from data mode to console
mode.
8. Input the password when prompted. Note that this page will only appear when the NPort 5100A has been
set up for password protection.
9. Start configuring the IP address under Network Settings. Refer to step 4 in the Telnet Console section
for the rest of the IP settings.
