PARAMETERS
Access to and, if necessary, editing of parameters is conditional upon 3 password levels: user, service and manufacturer.
Parameters that can be edited at user level are also available in the 2 higher levels (service and manufacturer). The editable
values at the service level can also be altered at the manufacturer level. Manufacturer parameters can be modified only at the
manufacturer level. Parameters in the Setpoint menu are not password-protected.
The table contains a list of the following:
• the parent menu and the mask code
• the parameter text that appears in the mask
• the parameter default value
• the unit of measurement
• the permissible range of values
Ref. Code Mask Field Level Value UDM Range
UNIT CONFIGURATION
01
CU001 Unit configuration Range Fixed ARIES
02
Model Fixed See Table 1
03
Version Fixed See Table 2 N/SN/SSN/H
04
Type Fixed chiller chiller/chiller+heat pump
05
CU002 Unit configuration Refrigerant Fixed R410a
06
Tank Fixed yes absent/present
07
Fans Fixed regulated
08
Fans configuration Fixed standard
09
Cycle inversion Fixed -
010
CU003 Unit configuration Pump 1 Fixed See Table 3 absent/present
011
Pump 2 Fixed See Table 3 absent/present
012
CU004 Unit configuration Heat recovery Fixed no no/yes
013
CU005 Unit configuration Defrost Fixed no no/yes
014
Chiller EEV Fixed no no/yes
015
Heat pump EEV Fixed no no/yes
016
CU006 Unit configuration Supervision User no no/yes
017
Supervision active User no no/yes
018
CU007 Unit configuration Remote ON/OFF enable User no no/yes
019
CH/HP remote enable User no no/yes
COMPRESSORS
020
CO02 Circuit compressors
type
Compressor 1 Fixed See Table 1
021
Compressor 2 Fixed See Table 1
022
CO03 Circuit compressors
type
Compressor 3 Fixed --
023
Compressor 4 Fixed --
FANS
