MAINTENANCE AND OPERATING MANUAL
Installation
HAS T 070÷140
41
ENGLISH
EN
The data in this manual are not binding and they can be modified by the manufacturer without notice. Reproduction of this manual is strictly prohibited.
8. Do not install the plant in sites exposed to strong winds; if unavoidable, install suitable windscreens.
4.3.3 Hydraulic connections
The unit is equipped with threaded or “Victaulic” connections (see diagram below).
1. Connect the unit to the water pipes as shown in the diagram below.
2. Provide two valves (one at the inlet, one at the outlet) to isolate the unit in the case of maintenance work without
having to empty the user water circuit.
3. If the unit is not equipped with a hydraulic unit as standard, ensure that the suction line of the pump installed
subsequently by the user is connected directly to the unit
in order to avoid excessively high pressure on the
condenser side.
