APPENDIX
SOUND LEVEL MEASUREMENTS
* at distance of 1 m
** global
Test conditions
Sound pressure level in hemispherical irradiation conditions at a distance of 1 m from the condenser side of the unit and height of
1.6 m from the ground.
Sound power level in compliance with ISO 3744.
Noise levels refer to operation of the unit at full load in nominal conditions. Values with tolerance of +/- 2 dB.
10.1 Settings table
The following table provides a list of all the masks that contain editable parameters of importance for operation of the unit.
If certain masks are not shown on the display this is not to be considered a malfunction.
ATTENTION
The display of certain masks or parts of masks depends on the configuration of the unit, which is decided in the design
stage.
All the masks are identified by a unique alphanumeric code shown in the Code column; the code is used in the manual to aid
quick identification of masks.
ATTENTION
Incorrect programming of the xDRIVE electronic controller can cause severe damage to the unit.
The parameters can be edited exclusively by properly qualified personnel.
Lw tot
dB(A)**
Lp tot
dB(A)*
Lw tot
dB(A)**
Lp tot
dB(A)*
AS T 070
N 93,6 80,6
AS T 080
N 92,6 79,6
SN 87,2 64,2
SN 86,0 73,0
SSN 78,9 65,9
SSN 78,9 65,9
H 92,6 79,6
H 92,6 79,6
AS T 090
N 92,6 79,6
AS T 100
N 92,6 79,6
SN 86,0 73,0 SN 86,0 73,0
SSN 77,7 64,7 SSN 77,7 64,7
H 91,7 78,7 H 91,7 78,7
AS T 110
N 92,6 79,6
AS T 120
N 92,6 79,6
SN 86,0 73,0
SN 86,0 73,0
SSN 78,7 65,7
SSN 78,7 65,7
H 93,3 80,3
H 93,3 80,3
AS T 130
N 93,3 80,3
AS T 140
N 93,3 80,3
SN 86,2 73,2 SN 86,2 73,2
SSN 79,1 66,1 SSN 79,1 66,1
H 92,3 79,3 H 92,3 79,3
