OPERATING AND MAINTENANCE MANUAL
Chapter 1 - General information
TAEevo Tech 015÷802 60 Hz UL
10
The data in this manual are not binding and they can be modified by the manufacturer without notice. Reproduction of this manual is strictly prohibited
ENGLISH
EN
1.2 How to interpret the alphanumeric string
The alphanumeric string is shown on the metal data plate on the cover page of this manual.
This symbol shown alongside appears in some refrigerant circuit diagrams and electrical
diagrams. This symbol refers to the alphanumeric string reported in the manual. The upper
box (X) identifies the position of the string, the lower box (Y) identifies the assigned value.
The empty alphanumerical string is circled in the adjacent figure; each
position in the upper row is associated with an alphanumeric value in the
lower row (0, 1, 2, A, B, etc.) and each character is associated with a
specific feature of the unit.
POS. VALUE DESCRIPTION
REFRIGERANTE 1 3 R410A
VOLTAGE 2 0 400/3/50
1 460/3/60
N 400/460/3/50-60
UNIT AMBIENT TEMPERATURE 3 0 STANDARD
1 -20°C
COMPRESSOR START-UP 4 0 DIRECT
2 SOFT STARTER
EVAP. FREEZE PROTECTION 5 0 NO
1YES
VERSION 6 STD STANDARD
ELECTRONIC THERMOSTATIC
VALVE
07 NO
1YES
LASER 8 A YES
BNO
C TEMPERATURE FINE REGULATION
FAN 9 A AXIAL
B CENTRIFUGAL
G HIGH PRESSURE AXIAL FLOW FANS
FAN CONTROL 10 1 ELECTRONIC CONTROL
3 ON/OFF
PRE-PAINTED CONDENSING COILS 11 0 NO
1YES
PUMP
13
R SP - Predisposed P3
IP3
LP5
PP3+P3
QP5+P5
TANK MATERIAL
14
1 Fe+Fe
2 Aisi+NoF
WATER BYPASS
15
1 OVERLOAD VALVE
2NO
KIT TYPE
16
A NO KIT
B TANK KIT
PRODUCT TYPE
1
7
0 STANDARD
X SPECIAL
0
1
12
CONDENSER COIL PROTECTION
NONE
FILTERS
