3.1.2 Characteristics of pumps and fans
NOTE
The values in the table may vary in relation to the unit model and configuration. In this case refer to the offer data.
NOTE
The pressure head is the pressure head available in the user’s premises. The installed pump my differ with respect to the
standard pump. For the flow rate and pressure head values two numbers are specified: the first refers to nominal conditions
and the second refers to maximum conditions.
3.1.3 Sound level measurements
Model TAEevo Tech 015 020 031 051 081 101 121 161
Tank
capacity
water volume (gal) 16 16 30 30 37 67 67 67
Pump P3
water flow rate (gpm) 2.0/21.1 2.0/21.1 3.8/21.1 4.8/21.1 9.5/42.3 12.1/42.3 15.2/85.4 18.0/85.4
pump pressure
head
(PSI) 44.9/25.4 44.9/25.4 44.1/28.7 43.7/29.9 43.1/22.2 42.4/25.8 42.5/23.4 42.3/24.4
rated power (kW) 0.75 0.75 0.75 0.75 0.9 0.9 1,85 1,85
Pump P5
water flow rate (gpm) 2.0/26.4 2.0/26.4 3.8/26.4 4.8/26.4 9.5/66.0 12.1/66.0 15.2/66.0 18.0/66.0
pump pressure
head
(PSI) 85.7/44.9 85.7/44.9 84.3/50.6 83.4/49.2 87.5/50.1 86.6/56.9 85.4/56.9 84.2/57.5
rated power (kW) 1.5 1.5 1.5 1.5 3.0 3.0 3.0 3.0
Axial flow
fan
No. of fans 11111222
total airflow (cfm) 2795 2470 4530 3590 5825 9945 9415 9415
Model TAEevo Tech 201 251 301 351 381 401 402 502
Tank
capacity
water volume (gal) 92.5 92.5 92.5 92.5 108 108 132 132
Pump P3
water flow rate (gpm) 19.0/84.5 19.0/84.5
26.5/
105.7
30.9/
105.7
39.5/
220.1
43.9/
220.1
37.9/
220.1
37.9/
220.1
pump pressure
head
(PSI) 42.4/28.9 42.4/28.9 45.9/19.3 45.2/18.5 52.2/20.4 52.1/20.4 52.4/25.0 52.4/25.0
rated power (kW) 1.8 1.8 2.2 2.2 4 4 4 4
Pump P5
water flow rate (gal)
19.0/105.7 19.0/105.7
26.5/
105.7
30.9/
105.7
39.5/
220.1
43.9/
220.1
37.9/
220.1
37.9/
220.1
pump pressure
head
(PSI) 75.6/47.7 75.6/47.7 74.8/47.8 74.0/47.0 77.6/42.9 77.2/42.9 77.7/47.6 77.7/47.6
rated power (kW) 4 4 4 4 7.5 7.5 7.5 7.5
Axial flow
fan
No. of fans 22332222
total airflow (cfm) 11535 11415 15625 15625 25662 24367 25895 25070
Model TAEevo Tech 602 702 802
Tank
capacity
water volume (gal) 132 179 179
Pump P3
water flow rate (gpm) 37.9/220.1 69.2/220.1 81.3/220.1
pump pressure
head
(PSI) 52.4/25.0 62.7/36.0 61.4/36.0
rated power (kW) 4 5.5 5.5
Pump P5
water flow rate (gal) 37.9/220.1 69.2/378.6 81.3/378.6
pump pressure
head
(PSI) 77.7/47.6 70.0/30.9 69.7/30.9
rated power (kW) 7.5 11.0 11.0
Axial flow
fan
No. of fans 2 3 3
total airflow (cfm) 24285 43967 42378
