OPERATING AND MAINTENANCE MANUAL
Chapter 3 - Technical data
TAEevo Tech 015÷802 60 Hz UL
17
The data in this manual are not binding and they can be modified by the manufacturer without notice. Reproduction of this manual is strictly prohibited
EN
ENGLISH
CHAPTER 3
TECHNICAL DATA
The data plate affixed to the unit bears the following technical data:
The performance of the unit depends mainly on the flow rate and temperature of water in the user circuit, and the
condenser thermal exchange fluid temperature. These values are defined at the time of the offer.
3.1 Data for standard units
3.1.1 Dimensions
See attached drawings.
MODEL and CODE The model number and the code identify the size of the unit and the type of
construction.
MANUAL Code number of the manual.
SERIAL NUMBER Construction number of the unit.
MANUFACTURING YEAR Year of unit’s final testing.
VOLTAGE/PHASE/FREQUENCY Electrical power supply characteristics.
MAX CURRENT DRAW (I max) Unit current draw in limit operating conditions.
SHORT CIRCUIT CURRENT Short circuit current.
HIGHER MOTOR FLA Max. absorbed current.
INSTALLED POWER (P max) Unit power input in limit operating conditions
PROTECTION RATING According to European standard EN 60529 / NEMA 250 international standard.
ELECTRICAL DIAGRAM Identifies the electrical diagram number.
REFRIGERANT Refrigerant fluid in the unit.
REFRIGERANT QUANTITY Quantity of refrigerant fluid contained in the unit.
USER CIRC. FLUID Type of user fluid utilised by the unit (normally water)
MAX ALLOWABLE PRESSURE (PS) Max. design pressure of the user circuit.
ALLOWABLE TEMPERATURE (TS) Minimum and maximum values of temperature of the user circuit; this should not be
confused with the maximum working temperature which is established when the
offer is made.
CONDENSER COOLING FLUID Fluid used by the unit to cool the condenser.
MAX WORKING PRESSURE Max. design pressure of the condenser cooling circuit (this data is not present if the
unit is air cooled condensed).
MAX. TEMPERATURE Condenser cooling circuit maximum design temperature (this information is not
given if the unit’s condenser is air-cooled).
SOUND PRESSURE LEVEL Free field sound pressure level in hemispherical radiation conditions (open field) at
a distance of 1 m from the condenser side of the unit and a height of 1.6 m from the
ground.
AMBIENT TEMPERATURE Minimum and maximum values of ambient air temperature.
WEIGHT Approximate weight of the unit before packing.
