OPERATING AND MAINTENANCE MANUAL
Chapter 7 - Electronic controller
TAEevo Tech 015÷802 60 Hz UL
53
The data in this manual are not binding and they can be modified by the manufacturer without notice. Reproduction of this manual is strictly prohibited
EN
ENGLISH
32. Auxiliary output pressure probe 2
33. Pressure probe for 4..20 mA dynamic set point
34. Oil pressure probe on compressor 1 or circuit 1
35. Oil pressure probe on compressor 2 or circuit 2
If the input is to be used as a digital input, the configuration will be from o1 to C75 and will take on the meaning seen in
“Configuration of digital inputs ID1 – ID18”
7.12.3 Configuration of digital inputs ID1 – ID11
0. Disabled
1. Remote ON / OFF
2. Remote Chiller / heat pump
3. Flow switch / delivery fan thermal cutout
4. Hot side flow switch
5. Antifreeze alarm on circuit 1
6. Antifreeze alarm on circuit 2
7. High pressure switch on circuit 1
8. High pressure switch on circuit 2
9. Low pressure switch on circuit 1
10. Low pressure switch on circuit 2
11. High pressure on compressor 1
12. High pressure on compressor 2
13. High pressure on compressor 3
14. High pressure on compressor 4
15. Not used
16. Not used
17. Thermal cutout on compressor 1
18. Thermal cutout on compressor 2
19. Thermal cutout on compressor 3
20. Thermal cutout on compressor 4
21. Not used
22. Not used
23. Condensation fan thermal cutout on circuit 1
24. Condensation fan thermal cutout on circuit 2
25. Common condensation fan thermal cutout
26. Evaporator water pump 1 thermal cutout
27. Evaporator support water pump thermal cutout
28. Condenser water pump 1 thermal cutout
29. Condenser support water pump thermal cutout
30. Recovery request on circuit 1
31. Recovery request on circuit 2
32. Defrost start/end on circuit 1
33. Defrost start/end on circuit 2
34. Energy Saving
35. Oil pressure switch / float switch on compressor 1
36. Oil pressure switch / float switch on compressor 2
37. Oil pressure switch / float switch on compressor 3
38. Oil pressure switch / float switch on compressor 4
39. Not used
40. Not used
41. Pump down pressure switch on circuit 1
42. Pump down pressure switch on circuit 2
43. Digital input for general unit block alarm 1
44. Digital input for general alarm signal / unit block alarm 2
45. Digital input for automatic RTC enable (time band) / manual mode (keypad)
46. Digital input for operation with delivery fan only
47. Digital input for temperature control request
48. Digital input for chiller request
49. Digital input for heat pump request
50. Digital input for power step 2 request
51. Digital input for power step 3 request
52. Digital input for power step 4 request
53. Digital input for power step 5 request
54. Digital input for power step 6 request
55. Digital input for power step 7 request
56. Digital input for power step 8 request
57. Digital input for power step 9 request
58. Digital input for power step 10 request
