5.3 Freeze protection
Even if the minimum operating temperature is higher than 0°C/32°F, during shutdown periods in the cold season the unit may
be subject to temperatures that are lower than 0°C/32°F.
In such cases if the water is not drained out of the unit ethylene or propylene glycol antifreeze should be added to the water
in the following percentages:
In accordance with the chilled water outlet temperature, to avoid the formation of ice ethylene or propylene glycol antifreeze
should be added to the water in the following percentages:
NOTE
The water flow rate must correspond to the value stated in the technical specifications or in the selection software.
The conditions specified in the table do not guarantee anti-freeze protection with the machine operating in bypass mode
between water delivery and return, and with the machine water inlet and outlet fittings shut off.
ATTENTION
The anti-freeze setting is 4°C/39°F. To reduce the anti-freeze setting edit parameter AL26.
For water outlet temperatures lower than 6 °C you must add a suitable quantity of antifreeze solution.
5.3.1 Operating limits
The operating limits are decided at the time of sale. Refer to the data specified in the contract.
Ambient T up to
[°C] (°F)
Ethylene Glycol
[% by weight]
Propylene Glycol
[% by weight]
0 (32) 0 0
-5 (23) 15 18
-10 (14) 25 27
-15 (5) 30 33
-20 (-4) 40 40
Water outlet T up to
[°C] (°F)
Ethylene Glycol
[% by weight]
Propylene Glycol
[% by weight]
Standard machine
7 (45) 0 0
3 (37) 20 20
0 (32) 20 25
-3 (27) 25 30
-5 (23) 30 30
-7 (19) 35 35
-10 (14) 35 40
Special machine
-15 (5) 45 45
-20 (-4) 50 50
Ambient air temperature
Evaporator water
inlet temperature
Evaporator water
outlet temperature
Water temperature
gradient
Min Max Min Max Min Max Min Max
°C/°F °C/°F °C/°F °C/°F
-5/23
43/109
(1)
0/32 35/95 -5/23 30/86
4/7 10/18
5/23
43/109
(1)
-5/23 35/95 -10/14 30/86
