OPERATING AND MAINTENANCE MANUAL
Chapter 7 - Electronic controller
TAEevo Tech 015÷802 60 Hz UL
47
The data in this manual are not binding and they can be modified by the manufacturer without notice. Reproduction of this manual is strictly prohibited
EN
ENGLISH
7.11.16 High condensing pressure unloading indication in chiller mode
7.11.17 High condensing pressure recovery disabling indication
Display labels meaning b1Cu (unloading indication from circuit 1 condenser coil)
b2Cu (unloading indication from circuit 2 condenser coil)
Cause of trip In operation if the probe configured as condensing pressure or temperature
control detects a value > CO44
Reset • if condensing pressure or temperature measures value < CO44 -
differential CO45
• with unloading active, after time setting Par. CO48
Reset Automatic
Icon Flashing
Action Alarm relay + buzzer NOT activated
Regulators
Alarm Relay + buzzer NOT activated
Inversion valve Follows its control
Recovery valve follows its control
Free cooling ON/OFF valve follows its control
Auxiliary relay follows its control
No-load start-up valve follows its control
Delivery fan Follows its control
Condensing fans Follows its control
Support /water heater /anti-freeze Follows its control
Evaporator/ condenser water pump(s) Follows its control
Compressors Follows its control
Pump down solenoid Follows its control
Display labels meaning b1rC (circuit 1 recovery disabling signal)
b2rC (circuit 2 recovery disabling signal)
Cause of trip In operation if the probe configured as condensing pressure control detects a
value > set rC06
Reset • If condensing pressure or temperature measures value < set rc06
- differential rC07
• From recovery disabling function activated after time set in
Par. rC08
Reset Automatic
Icon Flashing
Action Alarm relay + buzzer NOT activated
Regulators
Alarm Relay + buzzer NOT activated
Inversion valve Follows its control
Recovery valve Off
Free cooling ON/OFF valve Follows its control
Auxiliary relay Follows its control
No-load start-up valve Follows its control
Delivery fan Follows its control
Condensing fans Follows its control
Support /water heater /anti-freeze Follows its control
Evaporator/ condenser water pump(s) Follows its control
Compressors Follows its control
Pump down solenoid Follows its control
