OPERATING AND MAINTENANCE MANUAL
Chapter 7 - Electronic controller
TAEevo Tech 015÷802 60 Hz UL
52
The data in this manual are not binding and they can be modified by the manufacturer without notice. Reproduction of this manual is strictly prohibited
ENGLISH
EN
7.12 iCHILL input/output configurations
7.12.1 Configuration of analogue inputs PB1 - PB2 – PB5 – PB6
0. Disabled
1. PTC temperature probe on delivery outlet of compressor n° 1
2. PTC temperature probe on delivery outlet of compressor n° 2
3. PTC temperature probe on delivery outlet of compressor n° 3
4. PTC temperature probe on delivery outlet of compressor n° 4
5. Not used
6. Not used
7. PTC temperature probe for solar panel temperature
8. NTC temperature probe on evaporator inlet
9. NTC temperature probe on evaporator outlet 1
10. NTC temperature probe on evaporator outlet 2
11. NTC temperature probe on evaporator common output/support heater management (air/air unit)
12. NTC temperature probe on common input for condenser hot water
13. NTC temperature probe on condenser hot water input of circuit 1
14. NTC temperature probe on condenser hot water input of circuit 2
15. NTC temperature probe on condenser hot water output of circuit 1
16. NTC temperature probe on condenser hot water output of circuit 2
17. NTC temperature probe on common output for condenser hot water
18. NTC temperature probe for free cooling mode
19. NTC temperature probe for external air temperature dynamic set point / boiler function / changeover
20. NTC temperature probe for combined defrost on circuit 1
21. NTC temperature probe for combined defrost on circuit 2
22. NTC temperature probe for auxiliary output on circuit 1
23. NTC temperature probe for auxiliary output on circuit 2
24. NTC temperature probe for domestic hot water temperature 1
25. NTC temperature probe for domestic hot water temperature 2
26. NTC temperature probe for solar panel temperature
27. NTC temperature probe for condensation on circuit 1
28. NTC temperature probe for condensation on circuit 2
If the input is to be used as a digital input, the configuration will be from o1 to C75 and will take on the meaning seen in
“Configuration of digital inputs ID1 – ID18”
7.12.2 Configuration of analogue inputs PB3 - PB4
0. Disabled
1. PTC temperature probe on delivery outlet of compressor n° 1
2. PTC temperature probe on delivery outlet of compressor n° 2
3. PTC temperature probe on delivery outlet of compressor n° 3
4. PTC temperature probe on delivery outlet of compressor n° 4
5. Not used
6. Not used
7. PTC temperature probe for solar panel temperature
8. NTC temperature probe on evaporator inlet
9. NTC temperature probe on evaporator outlet 1
10. NTC temperature probe on evaporator outlet 2
11. NTC temperature probe on evaporator common output/support heater management (air/air unit)
12. NTC temperature probe on common input for condenser hot water
13. NTC temperature probe on condenser hot water input of circuit 1
14. NTC temperature probe on condenser hot water input of circuit 2
15. NTC temperature probe on condenser hot water output of circuit 1
16. NTC temperature probe on condenser hot water output of circuit 2
17. NTC temperature probe on common output for condenser hot water
18. NTC temperature probe for free cooling mode
19. NTC temperature probe for external air temperature dynamic set point / boiler function / changeover
20. NTC temperature probe for combined defrost on circuit 1
21. NTC temperature probe for combined defrost on circuit 2
22. NTC temperature probe for auxiliary output on circuit 1
23. NTC temperature probe for auxiliary output on circuit 2
24. NTC temperature probe for domestic hot water temperature 1
25. NTC temperature probe for domestic hot water temperature 2
26. NTC temperature probe for solar panel temperature
27. Condensation probe on circuit n° 1 (NTC temperature / pressure 4÷20 mA / ratiometric 0÷ 5Volt)
28. Condensation probe on circuit n° 2 (NTC temperature / pressure 4÷20 mA / ratiometric 0÷ 5Volt)
29. Evaporation pressure probe in circuit 1
30. Evaporation pressure probe in circuit 2
31. Auxiliary output pressure probe 1
