OPERATING AND MAINTENANCE MANUAL
Chapter 7 - Electronic controller
TAEevo Tech 015÷802 60 Hz UL
55
The data in this manual are not binding and they can be modified by the manufacturer without notice. Reproduction of this manual is strictly prohibited
EN
ENGLISH
48. Remote standby/off machine status
49. Water side solenoid valve on circuit 1
50. Water side solenoid valve on circuit 2
51. Direct start-up: compressor 1 relay
PW start-up: winding 1 relay on compressor 1
52. PW start-up: winding 2 relay on compressor 1
53. Step capacity control 1 on compressor 1
54. Step capacity control 2 on compressor 1
55. Step capacity control 3 on compressor 1
56. Gas bypass valve on start-up of compressor 1
57. Direct start-up: compressor 2 relay
PW start-up: winding 1 relay on compressor 2
58. PW start-up: winding 2 relay on compressor 2
59. Step capacity control 1 on compressor 2
60. Step capacity control 2 on compressor 2
61. Step capacity control 3 on compressor 2
62. Gas bypass valve on start-up of compressor 2
63. Direct start-up: compressor 3 relay
PW start-up: winding 1 relay on compressor 3
64. PW start-up: winding 2 relay on compressor 3
65. Step capacity control 1 on compressor 3
66. Step capacity control 2 on compressor 3
67. Step capacity control 3 on compressor 3
68. Gas bypass valve on start-up of compressor 3
69. Direct start-up: compressor 4 relay
PW start-up: winding 1 relay on compressor 4
70. PW start-up: winding 2 relay on compressor 4
71. Step capacity control 1 on compressor 4
72. Step capacity control 2 on compressor 4
73. Step capacity control 3 on compressor 4
74. Gas bypass valve on start-up of compressor 4
75. Laser function valve
7.12.5 Configuration of proportional outputs OUT1 and OUT2 (0 – 10 VOLT)
0. Output disabled
1. 0-10V output for evaporator pump in modulating mode
2. 0-10V free cooling modulating output
3. Laser function output
4. 0-10V auxiliary output 1
5. 0-10V auxiliary output 2
6. 0-10V output inverter compressor on circuit 1
7. 0-10V output inverter compressor on circuit 2
8. 0-10V output condensation fans on circuit 1
9. 0-10V output condensation fans on circuit 2
ON/OFF output, relay pilot, to enable configuration of a proportional output with the same characteristics as a digital output.
The displayed values range from o1 to c50, as per the digital outputs.
7.12.6 Configuration of proportional outputs OUT3 and OUT4 (0 – 10 VOLT/PWM)
0. 10 Output disabled
1. 0-10V output for evaporator pump in modulating mode
2. 0-10V free cooling modulating output
3. Laser function output
4. 0-10V auxiliary output 1
5. 0-10V auxiliary output 2
6. 0-10V output inverter compressor on circuit 1
7. 0-10V output inverter compressor on circuit 2
8. 0-10V output condensation fans on circuit 1
9. 0-10V output condensation fans on circuit 2
10. PWM output condensation fans on circuit 1
11. PWM output condensation fans on circuit 2
ON / OFF output, relay pilot, to enable configuration of a proportional output with the same characteristics as a digital
output. The displayed values range from o1 to c50, as per the digital outputs.
