4.1 SYSTEM OVERVIEW (CONTINUED)
F
IGURES 4-1 through 4-7 refer to all controls, indicators and connections on the Model 3000.
Their associated descriptions are as follows:
Item
#
Name Description
21 CASSETTE ADMINISTRATION TUBE
PROVIDES IRRIGATION INPUT FOR TUBING
CASSETE
22 TUBING CASSETTE
PROVIDES SYSTEM CONNECTION FOR
IRRIGATION AND ASPIRATION FUNCTIONS
23 COLLECTION TUBE
PROVIDES WASTE OUTPUT TO COLLECTION
BAG
24 COLLECTION BAG HANGER HANGER FOR THE COLLECTION BAG
25 IRRIGATION TUBE
PROVIDES IRRIGATION INPUT FOR
ULTRASONIC HANDPIECE
26 ASPIRATION TUBE
PROVIDES ASPIRATION OUTPUT FOR
ULTRASONIC HANDPPIECE
27 HEEL REST
PROVIDES STABLE SURFACE FOR LEVERAGE
ONTO TREADLE
28 MAIN TREADLE
ACTIVATES THE BASIC MODES OF THE
SYSTEM, USER INTERFACE FOR CONTROLS
29 LEFT SWITCH (SIDE KICK)
ACTIVATES ASSIGNED FUNCTIONS (DEFAULT:
NOT USED)
30 RIGHT SWITCH (SIDE KICK)
ACTIVATES ASSIGNED FUNCTIONS (DEFAULT:
REFLUX)
31 ASPIRATION PORT
PROVIDES CONNECTION FOR ASPIRATION OF
WASTE
32 IRRIGATION PORT
PROVIDES CONNECTION FOR IRRIGATION
FLUID
33 U/S HANDPIECE
SOLID TITANIUM CONSTRUCTION.
COMPATIBLE WITH MTP PHACO(S).
34 HANDPIECE ELECTRICAL CONNECTOR
PROVIDES POWER TO THE ULTRASONIC
HANDPIECE
35 SOLUTION HANGER HANGER FOR SUSPENDING SOLUTION BOTTLE
36 HANDLE HAND GRIP FOR MOVING THE CART
37 SHELF
PROVIDES SECURE MOUNTING LOCATION FOR
SYSTEM CONSOLOE
38 CABLE MANAGEMENT
STORES THE WRAPPED POWER CORD WHEN
NOT IN USE
39 FOOT PEDAL HANGER STORES THE FOOT PEDAL WHEN NOT IN USE
40 ACCESSORY TRAY
PROVIDES CONVENIENT LOCATION FOR
HANDPIECES AND ACCESSORIES
