9.0 SYSTEM SERVICE
This section of the manual contains the information for Fuse replacement, System Maintenance,
System Repairs, and Technical Support.
9.1 FUSE REPLACEMENT
The AC Power input module contains two (2) fuses that protect the unit from excessive power
loads and power line fluctuations. The module is located on the back of the back panel of the unit.
(Refer to Section 4.1 System Overview and FIGURE 4-1, item #8 for fuse location)
If a power surge occurs, these fuses may need to be replaced. Always replace these fuses with
the exact same fuse rating (5 x 20 mm 250V T 5.0A) fuses. These fuses are also available from
Medical Technical Products, LP (MTP) part # 430-2215-002.
WARNING: ELECTRICAL HAZARD!
Disconnect the Model 3000 from all electrical power before performing the following steps.
To replace the fuse, perform the following steps:
9.1.1 On the back panel of the system, press the power switch to the “O” OFF position.
9.1.2 Remove the AC power cord from the system back panel for easy access to the fuse
panel.
9.1.3 Use a small flat-tipped screwdriver to pull out on the notch on the fuse cover tab
above the power switch and pull the cover down. Once the fuse cover is off, the fuse
holders can be removed.
9.1.4 Push the fuse holder in the opposite direction of the arrow on top of the holders and
then pull up on the holders.
9.1.5 Remove the old fuses and replace them with the new 5 x 20 mm 250V T 5.0A fuses.
9.1.6 Push the fuse holders back into place towards the arrows on top of the holders.
9.1.7 Push the fuse cover back into place until it snaps closed.
9.1.8 Connect the AC power cord to the back panel of the system.
9.1.9 On the back panel of the system, press the power switch to the “I” ON position.
9.1.10 Verify that the Model 3000 powers up and the U/S Phaco screen (default) is displayed.
NOTE: If the Model 3000 does not power up after the fuse replacement check, contact your
regional distributor.
