6.2.4 ULTRASONIC HANDPIECE
6.2.4.1 Connect the aspiration tube from the cassette (female fitting) to the ultrasonic
handpiece aspiration port (male fitting).
6.2.4.2 Connect the irrigation tube from the cassette (male fitting) to the ultrasonic handpiece
irrigation port (female fitting).
6.2.4.3 Install the phaco tip onto the U/S handpiece using the supplied tip wrench, tighten until
fully seated.
CAUTION: DO NOT over-tighten or thread damage to the handpiece may occur.
6.2.4.4 Carefully attach threaded irrigation sleeve over U/S tip, exposing desired amount of tip,
with the irrigation ports on the tip sleeve perpendicular to the furthermost part of the tip
bevel.
