8.2 CLEANING THE SYSTEM CONSOLE
8.2.1 On the back panel of the system, press the power switch to the “O” OFF position.
8.2.2 Disconnect the Model 3000 from all electrical power.
8.2.3 Use a soft cloth dampened with mild soap and water to remove dirt and residue from
the touchscreen.
8.2.4 Dry the touchscreen with a soft lint-free cloth to prevent water spots.
CAUTION: DO NOT use cleaning solutions on the front panel touchscreen.
8.2.5 Clean the surface of the console with either 70% isopropyl alcohol or a mild soap and
water solution.
8.2.6 Use a small amount of cleaning solution around the electrical and pneumatic
connectors on the side and on the back panel of the system.
8.2.7 Thoroughly wipe the console with a soft lint-free cloth to remove all cleaning solution or
soap and water. DO NOT leave any cleaning solution residue or water spots on the
console surface.
8.3 CLEANING THE FOOT PEDAL
8.3.1 On the back panel of the system, press the power switch to the “O” OFF position.
8.3.2 Disconnect the Model 3000 from all electrical power.
8.3.3 Clean the surface of the foot pedal with either 70% isopropyl alcohol or a mild soap
and water solution.
8.3.4 Thoroughly wipe the foot pedal with a soft lint-free cloth to remove all cleaning solution
or soap and water. DO NOT leave any cleaning solution residue or water spots on the
foot pedal surfaces.
8.3.5 Gently clean the connecting cable at end of each day using either 70% isopropyl
alcohol or a mild soap and water solution.
8.3.6 After cleaning, examine the foot pedal connecting cable for nicks, tears and wear
fractures in the cable sheath.
NOTE: The foot pedal should be wiped clean of any fluids that come in contact with it during the
course of the surgery. The surface of the foot pedal could corrode or rust if not thoroughly
cleaned.
