5.0 SYSTEM OPERATION OVERVIEW
This section of the manual contains the information that identifies the operational functionality
of the system which includes the following:
 Operational Modes
 Mode Functionality
 Parameter Settings
 Optional Commands for additional operation
WARNING: This information should be completely read and understood in its
entirety
before operating the system in order to avoid harm to the system and/or the
patient.
5.1 SYSTEM SOFTWARE OVERVIEW
The System Software (Factory Default Settings) Overview may be used as a quick
reference guide or navigate to the various screens and menus of the system operation.
MAIN MENU (U/S)
NORMAL (U/S)
IRRIGATION (IRR)
IRRIGATION /
1. Normal
1.1 U/S Power %
1. ON / OFF
ASPIRATION (I/A)
2. Burst
1.1.1 Fixed Power
2. Bottle Height
1. Flow (cc/min)
3. Micro
1.1.2 Linear Power
1.1 Fixed Flow
4. Irrigation ON/ OFF
1.2 Pulse (pulse/sec)
1.2 Linear Flow
5. Bottle Height
1.3 Flow (cc/min)
2. Vacuum (mmHg)
6. Prime
1.4 Vacuum (mmHg)
2.1 Fixed Vacuum
7. Tune
2.2 Linear Vacuum
8. Reset
3. Irrigation ON / OFF
9. Purge
4. Bottle Height
BURST (U/S)
VITRECTOMY (VIT)
2.1 U/S Power %
1. Cut Rate (cuts/min)
2.2 Burst (% - ms)
1.1 Single Cut
2.2.1 Single Burst
1.2 Multi Cut
2.2.2 Multi Burst
2. Flow (cc/min)
2.3 Flow
2.1 Fixed Flow
COAGULATION
2.4 Vacuum
2.2 Linear Flow
(COAG)
3. Vacuum (mmHg)
1. Power
3.1 Fixed Vacuum
1.1 Fixed Power
3.2 Linear Vacuum
1.2 Linear Power
MICRO (U/S)
4. Irrigation ON / OFF
3.1 U/S Power %
5. Bottle Height
3.1.1 Fixed Power
3.1.2 Linear Power
3.2 ON / OFF (ms)
3.3 Flow (cc/min)
3.4 Vacuum (mmHg)
