5.4.5 MULTIMODE (U/S) SOFT-KEYS 1, 2, 3
The Multimode soft-keys are used as Phaco Mode presets for quick access to user- programmed
Phaco Modes. The user can select any of the three (3) multimode soft-keys and edit default Phaco
programs by completing the following steps:
5.4.5.1 Select any multimode soft-key.
5.4.5.2 Select any of the Phaco Tabs: Normal, Burst, or Micro.
5.4.5.3 Edit any of the following Phaco parameters for the Phaco Tab selected:
Normal Tab Burst Tab Micro Tab
U/S Power (%) U/S Power (%) U/S Power (%)
Pulse (pulses/s) Burst (% - ms) Burst On / Off (ms)
Flow (cc/min.) Flow (cc/min.) Flow (cc/min.)
Vacuum (mmHg) Vacuum (mmHg) Vacuum (mmHg)
Fixed Single Fixed
Linear Multi Linear
Bottle Height Bottle Height Bottle Height
5.4.5.4 Select another multimode soft-key.
5.4.5.5 Select another Phaco Tab and edit any of the Phaco parameters.
5.4.5.6 Now select the first multimode soft-key you previously edited. The edited Phaco
parameters should be as first edited.
NOTE: The edited Phaco parameters will remain as edited until the system is
powered OFF.
The Phaco parameters will return to the default factory settings when the system is powered ON.
