4.0 SYSTEM DESCRIPTION
4.1 SYSTEM OVERVIEW
FIGURES 4-1 through 4-7 refer to all controls, indicators and connections on the Model 3000.
Their associated descriptions are as follows:
Item
#
Name Description
1 REAR PANEL LABEL
DISPLAYS SYSTEM RATINGS, SERIAL NUMBER,
ALL WARNINGS AND CAUTIONS
2 ON / OFF SWITCH I (ON) ; O (OFF)
3 RJ 45 CONNECTOR FACTORY USE
4 USB PORTS 1 & 2 FACTORY USE
5 FOOTPEDAL CONNECTOR CONNECTION FOR THE SYSTEM FOOT PEDAL
6 IV POLE CONNECTOR
CONNECTION FOR THE OPTIONAL CART WITH
AUTOMATED IV POLE
7 AC POWER INPUT
PROVIDES POWER CONNECTION AND
OVERLOAD PROTECTION TO THE SYSTEM
8 FUSE HOLDER CONTAINS TWO SYSTEM FUSES
9 CASSETTE LOCK
LOCKING MECHANISM FOR THE TUBING
CASSETTE
10 VENT VALVE CONTROLS ASPIRATION LINE VENTING
11 IRRIGATION VALVE CONTROLS FLOW OF IRRIGATION FLUID
12 CASSETTE RELEASE BUTTON RELEASES THE CASSETTE WHEN PRESSED
13 ULTRASONIC CONNECTOR
PROVIDES POWER TO THE ULTRASONIC
HANDPIECE
14 COAGULATION CONNECTOR
PROVIDES POWER TO THE CAUTERY
FORCEPS
15 VITRECTOMY PORT PROVIDES AIR TO THE VITRECTOR
16 PERISTALTIC PUMP HEAD PROVIDES FLOW FOR SYSTEM ASPIRATION
17 VACUUM SENSOR SENSOR FOR MEASURING VACUUM
18 TOUCHSCREEN DISPLAY PROVIDES ACCESS TO USER INTERFACE
19 FRONT PANEL
PROVIDES DISPLAY FOR THE SYSTEM
OPERATION
20 SPEAKERS
PROVIDES AUDIBLE VOICE, INDICATORS AND
ALERTS
