5.9.16 FOOT PEDAL MODE (CONTINUED)
The foot pedal RIGHT and LEFT Side Kick Modes have the same operations as follows:
Not Used
Reflux
Mode
Multimode
Irrigation
IV Pole
As noted in the FACTORY settings:
Factory default operation for RIGHT Side Kick Mode is “REFLUX”
Factory default operation for LEFT Side Kick Mode is “Not Used”
The foot pedal RIGHT and LEFT Side Kick Mode settings can be changed to any combination of the
six (6) operational functions listed.
Not Used: When this option is selected, the selected side kick has NO function.
Reflux: When this option is selected, the selected side kick function is “Reflux” in any foot pedal main
treadle position.
Mode: When this option is selected, and the foot pedal main treadle is not depressed (Side Kicks
ONLY), the selected side kick function will switch between main modes of operation: IRR, U/S, I/A,
VIT and COAG.
Multimode: When this option is selected, and the foot pedal main treadle is not depressed
(Side Kicks ONLY), the selected side kick function will switch between Multimodes 1, 2, and
3 in U/S Phaco Mode, and between Multimodes I/A1, I/A2, and Cap Vac in I/A Mode.
Irrigation: When this option is selected, and the foot pedal main treadle is not depressed
(Side Kicks ONLY), the selected side kick function will perform the following:
Press the Side Kick – Switch ON the Irrigation function
Press the same Side Kick – Switch OFF the Irrigation function
IV Pole: When this option is selected, and the foot pedal main treadle is not depressed
(Side Kicks ONLY), the selected side kick function will perform the following functions:
Tapping the side kick one (1) time will raise the IV pole one (1) inch each tap.
Pressing and holding the side kick will raise the IV pole until the side kick is released
Tapping the side kick two (2) times will lower the IV pole (1 inch) each double tap
Double tapping and holding the side kick will lower the IV pole until the side kick is
released.
