7.8 SYSTEM MESSAGES (CONTINUED)
IRR MESSAGES DESCRIPTION
Check Cassette!
Cassette not seated properly - should click into place
when fully seated across lock mechanism.
Check Footpedal!
Check cable of foot pedal for condition,
Check foot pedal not plugged in.
PROGRAM MESSAGES DESCRIPTION
Add Program
Message will be displayed when the “ADD” button is
pressed. Enter the program name, and it will appear in
the program list box at the top of the screen.
Delete Program
Message will be displayed when the “DELETE” button
is pressed. Select the program from the list box to
delete and press “OK”
Rename Program
Message will be displayed when the “RENAME”
button is pressed. Select the program from the list box
to rename, type in the new name, and press “OK”
Save Program
Message will be displayed when the “UPDATE” button
is pressed. Select the program from the list box to
update and press “OK”
CALIBRATION MESSAGES DESCRIPTION
Move to First Detent! Depress the foot pedal until “OK” button is enabled.
Set First Detent! Set the first detent position; press “OK” button.
Move to Second Detent! Depress the foot pedal until “OK” button is enabled.
Set Second Detent! Set the second detent position; press “OK” button.
Depress the Footpedal! Depress the foot pedal completely.
Set Down Position!
With the foot pedal completely depressed, press the
“OK” button.
Release the Footpedal! Let the foot pedal return to non-depressed position.
Set Released Position!
With the foot pedal in non-depressed position, press
the “OK” button.
