XR21S59 CHU 14
1/2018
113813003
Hooklift Multilift XR21S59 CHU
User Manual
SYSTEM OPERATION IN MANUAL MODE
Manual mode must be used in special situations, such as handling longer or shorter atrack/
bodies than usual, handling containers in shallow spaces or on uneven ground and loading
or unloading them on/from a platform or a trailer.
The movements take place in mode A5 (push the A5 button on the control unit for 2 seconds).
When the mode is engaged, A5 will blink on the control unit display.
The mode will disengage by pushing the A5 button again, or automatically after 10 min if
no operations have been used during this time.
The horizontal movement is prevented when it is more to the front than the front position
of atrack/body change (approx. 350 mm behind the far-front position = “STOW/UNSTOW
POSITION”). The liftframe ratchets must also be attached to the stowage. Otherwise ”d019”
will be visible on the control unit display.
In manual mode the main cylinders are controlled by moving the control lever to the front and
the back. If the body locks are open, the XR21S -equipment is in loading/unloading mode.
If they are closed, the XR21S -equipment is in tipping mode. See terms of use in mode A2.
The telescope cylinder is controlled by rocker switches on the sides of control unit, by
pushing its front or back. The body locks must be open. The horizontal cylinder stroke has
not been restricted.
The movements in manual mode should be phased as in automatic mode.
As explained earlier, the horizontal movement is long, and during atrack/body change it
has been restricted to approx. 350 mm before the far-front position.
