Hooklift Multilift XR21S59 CHU
User Manual
CHANGING OPERATION IN DIFFERENT SITUATIONS
Each operation can be stopped at any time by releasing the switch, and continued or
changed depending on the operation phase (but not changed e.g. from tipping to changing
the atrack/body) by going to the desired operation and pressing its switch.
Changing the control method (automatic mode/manual mode)
1. Changing from automatic mode to manual mode
The control method can always be changed to manual, under all circumstances.
2. Changing from manual mode to automatic mode.
2.1 Automatic mode can be engaged, if the tilting movement is fully in the front
position, the locks will close
- tipping and unloading are possible.
2.2 Automatic mode cannot be engaged if the tilting movement is in a position
other than front position, a warning buzzer can be heard in the cabin.
AUTOMATIC MODE should be used whenever possible.
Automatic mode can be used during loading and unloading of containers with widely
used lengths.
The atrack/body length in automatic mode should be:
at least 4,6 m (G-size - 0,7 m) G-size = geometric length of the equipment 5,3 m,
max. 6,3 m (G-size + 1,0 m) measurement from the middle line of the hook to the
middle of the rear rollers
Shorter or longer containers must be handled in manual mode.
Even containers with these dimensions should be handled in manual mode
when loading on uneven ground.
