XR21S59 CHU 199
1/2018
113813003
Hooklift Multilift XR21S59 CHU
Service Manual
>>>
ERROR CODE
COMMENTS / PROBLEM LOCATION
PROGRAM DESCRIPTION POSSIBLE ACTION CONSEQUENCE
d019
CATCH LOCKING LEFT ARE ACTIVE
CATCH LOCKING LEFT ARE ACTIVE OPEN THE LEFT SIDE CATCH LOCKING / CHECK
THE SENSOR
NO HOOKLIFT
FUNCTION
d020
URB IS IN
URB IN WRONG POSITION
d021
URB IS OUT
URB IN WRONG POSITION
d022
URB IS IN MIDDLE POSITION
URB IN WRONG POSITION
d023
Not in use
d024
Not in use
d025
LIFT FRAME NOT STOWED LIFT FRAME STOWED SENSOR INACTIV SLIDING BWD IS
PREVENTED
d026
STOWAGE IS NOT IN OPERATE STOWAGE HOOKS IN STOWAGE HOOKS
ARE NOT IN
d027
HOOKLIFT IS DISABLED / ROAD MAT IS ON
ROAD MAT FUNCTION IS ON SWITCH THE ROAD MAT FUNCTION OFF NO HOOKLIFT
FUNCTION
d028
MIDDLE FRAME IS NOT MOVED TO REAR
POSITION
HOOK LOCK IS NOT ENABLED MOVE MIDDLE FRAME TO REAR POSITION OR
CHECK THE TILT INDICATOR
