ERROR CODE
COMMENTS / PROBLEM LOCATION
PROGRAM DESCRIPTION POSSIBLE ACTION CONSEQUENCE
d040
MODES A1 AND A2 NOT ENGAGING SLIDE FRAME
SLIDE IN CONTAINER AREA MOVE SLIDE FRAME TO FLATRACK/BODY AREA SLIDE FRAME TOO FAR
FORWARD
d041
SLIDE FRAME
SLIDE IS NOT IN FRONT OPERATE SLIDE FRAME TO FRONT SLIDE FRAME TO MUCH
BACK
d042
TILTING ARM IS NOT MOVING IN A5 MODE WHEN
MIDDLE FRAME IS DOWN OR AUTOMATIC
MODES A1/A2 CANNOT BE ACTIVATED WHEN
MIDDLE FRAME IS UP AND SLIDE ISN´T IN BACK
POSITION
SLIDE FRAME
SLIDE NOT IN BACK POSITION OPERATE SLIDE FRAME FULLY BACK SLIDE FRAME IS NOT
FULLY BACK OR THE
SENSOR IS NOT ACTIVE
d044
SLIDE NOT FUNCTIONING
SLIDING OUTOF RANGE CHECK LINEAR SENSOR OF SLIDE FRAME AND
CABLES
VALUES FROM LINEAR
SENSOR OF SLIDE FRAME
CYLINDER DIFFER FROM
CALIBRATION
