Hooklift Multilift XR21S59 CHU
User Manual
Ensure that the load´s centre of gravity is as low as possible and that it is in the middle
of the atrack/body and evenly distributed. If the load must be secured, do this when the
atrack/body is on the ground.
Ensure before loading or unloading of the atrack/body that all the removable equipment
are safely fastened and that the load space tail gate, side doors and the load’s fastening
have been checked.
Reverse the truck as slowly as possible to avoid damaging the atrack/body, the load or
the XR hooklift equipment.
If the truck is not in line with the atrack/body, position the atrack/body in line by lifting the
front end of it approx. 10 cm and pulling it forward by truck. This will prevent the atrack/body
from being pulled outside the rear rollers, and the hooklift and rear lights being damaged.
When moving the atrack/body to get it in line with the truck, rst remove all obstacles in
front of the atrack/body.
When loading or unloading a atrack/body, ensure that the hydraulic body locks are open.
The corresponding control unit signal light is lit when the locks are open.
Remember that the maximum permissible speed of the pump = the recommended engine
speed. Let the engine run at idle speed while switching the hydraulic body locks on and
o. Each movement must begin and end at idle speed of engine and at low speed of the
tipping cylinders. In addition the recommended pump speed (= engine speed) must not
be exceeded.
