Creating and customising models
Selecting a template
Thanks to pre-defined model templates (see page 53) new models can be created
more easily and quickly since the basic configuration is more or less completed by
selecting the template.
You can use the Memory > Edit name menu to find out which template was used
for model creation.
4. Select the HELIccpm model template for the Template parameter.
Inheriting parameters from the active model
5. Select the data to be inherited from the currently active model.
a. Ctrl Mode: Usually, the basic control functions will always remain on
the same stick axes. So, keep the switch setting "ON".
b. Ctrls assignment: When you select "ON", the assignments of controls
to control functions are inherited from the current model. When set to
"OFF", they are inherited from the template.
c. Switch assignment: When you select "ON", the assignments of
switches to switched functions are inherited from the current model.
When set to "OFF", they are inherited from the template.
d. Names of Controls: When you select "ON", the names of the control
functions are inherited from the current model. When set to "OFF",
they are inherited from the template. If you changed the names in the
current model and you would like to inherit these names, "ON" should
be selected. Otherwise, setting the switch to "OFF" is preferable.
e. Sensor names: When you select "ON", the names of the sensors are
inherited from the current model. When set to "OFF", they are inherited
from the template. If you changed the names in the current model and
you would like to inherit them, "ON" should be selected. Otherwise,
setting the switch to "OFF" is preferable.
The device stores your selection. In most cases, you just have to check the
selection switches.
Confirming settings
6. Confirm the setting with OK: The model memory is created and immediately
activated. The display automatically switches to safety check and status
display.
