PROFI TX
5.1.4 Status displays #4 to #8
The status displays #4 to #8 show three sensor values each.
1
Sensors:
 Sensor address
 Sensor name
 Sensor value
 Unit
The inverted display of a line indicates that the sensor reports an alarm.
The value is shown crossed out if no sensor signal is received for several
seconds.
The minimum / maximum values are displayed while pressing and holding
the ENTER button. This is only possible if a receiver with backlink provides
data to display!
3
Alternative:
 Status of the digi-adjusters, if used (see section 5.1.2 "Status display #2"
on page 87).
 Name of the model memory, if no digi-adjuster is assigned.
3
Trim display (see section 5.1.2 "Status display #2" on page 87).
All minimum / maximum memories are erased when you press the REV/CLR
button in the status displays #4 to #8.
1
2
3
3
