Multiplex PROFI TX 9 User Manual

Transmitter
PROFI TX
Page 35
3.3.3 Installing stick tops with a switch or button
MULTIPLEX
®
offers three different stick tops with switch or button for the PROFI TX
(see section 10.2 "Accessories" on page 213).
To install a new stick top, proceed as follows:
1. Switch off the transmitter and open it.
2. Remove the battery
1
.
3. Loosen the grub screw at the bottom of the stick top (1.5mm slot-head
screwdriver).
4. Pull off the top from the stick shaft.
5. Wrap the flexible wires of the new stick top with a thin enamelled copper wire.
Tightly bend back the insulated section. Thread the wire through the threaded
coupler of the stick shaft until it is visible at the bottom of the stick unit. Use a
pair of pliers to pull the wire out until you can grab it with your fingers.
1
After re-inserting the battery, the date and time need to be set again.
