4.1.3 GLIDER+ model template
 The model template is suitable for glider-type models with up to 8 flaps,
optionally with snap flap.
Servo assignment
Pre-defined mixers on the control side, with 2 more that can be defined by
the operator.
Name
Mixer inputs
Options & settings
Value
Combi-Switch
Ail <> rudder
Ail < rudder
OFF
Differnt.Ail
Aileron
Mode
Differnt.Ail
ON
50%
Pre-defined mixers on the servo side
Name
Mixer inputs
Options & settings
Value
ELEVATOR+
Elevator
š
Up and down travels
are asymmetrical
100%
100%
Spoiler
œ
Single-sided travel,
with intermediate point
OFF
OFF
Flap
š
Up and down travels
are asymmetrical
OFF
OFF
Function
1+5
AILERONS+
2
ELEVATOR+
3
Rudder
4
Throttle
Fig. 10: GLIDER+ servo assignments
6+7
FLAP_INNR+
8+9
Spoiler
