2. Introduction
We are delighted that you have decided to purchase the
MULTIPLEX ROYALevo radio control system. The
ROYALevo was introduced early in 2002, and constitutes
a modern digital radio control system, which represents
a further milestone in the development of radio control
systems by MULTIPLEX. In the overall design, develop-
ment and production of this system we have invested
all our experience of several generations of radio con-
trol equipment. The result is a universal, ergonomically
efficient radio control system of modern design which is
simple to operate, and which is suitable for use both
hand-held and in a transmitter tray. And - not least - the
ROYALevo is MADE IN GERMANY.
We placed particular emphasis on convenience of op-
eration during the development of the system software.
The ROYALevo offers you a wide range of functions
selected by experienced users, and these cope effort-
lessly with any model from simple two-axis gliders to
complex large-scale models and helicopters. Despite its
comprehensive features, the transmitter is simple to
operate and easy to understand.
The essential features of the ROYALevo are as follows:
• Ergonomically efficient case, suitable for hand-held
or tray use, with precision stick units which swivel
to suit your personal preference
• Graphical folding screen (132 x 64 pixels) with variable
contrast
• Easily accessible digital trims in a cruciform arrange-
ment, giving an entirely new feeling to the trims
• Low-cost standard RF module* with plug-in crystals, or
synthesizer RF module* with software channel selection
• 9 or 12 channels
• 20 or 36 model memories
• 6 menu buttons for fast, direct access to the main
menus
• 5 function buttons and two 3-D digi-adjustors for user-
friendly programming
• Detailed menu texts, selectable language, various lan-
guages available
• Comprehensive set-up and mixer facilities for fixed-wing
models and helicopters
• Sample models (templates) minimise programming
effort required
• Unrestricted assignment of transmitter controls,
switches and servos
• 4 flight phases per model memory
• 5 timers
(3 alarm timers + transmitter and model times)
• Facilities for selective Teacher/Pupil (Trainer) operations
as standard
We are confident that you will quickly learn to appreci-
ate the ROYALevo, and enjoy using it to control your
models over a period of many years. Please take a little
while to familiarise yourself with the system, referring
constantly to these instructions which are intended to
help you.
Yours – the MULTIPLEX team
Options:
* MULTIPLEX Channel-Check power-on guard system
** Scanner with power-on guard function
See the main MULTIPLEX catalogue for frequency ranges available.
3. Safety notes
! These operating instructions are an integral part
of the product, and contain important informa-
tion and safety notes. They should therefore be
stored in a safe place where you can refer to
them at any time. If you ever dispose of the
equipment be sure to pass on the instructions to
the new owner.
! Read these safety notes!
Read the instructions carefully! Please do not at-
tempt to use the equipment until you have read
these operating instructions thoroughly, to-
gether with the following safety notes (included
in these instructions or supplied separately).
! It is not permissible under any circumstances to
make technical modifications to the radio control
system itself or its components. Use genuine
MULTIPLEX accessories and replacement parts
exclusively (especially transmitter battery, crys-
tals, aerial, ...).
! If you wish to use the system in conjunction with
products made by other manufacturers, it is up
to you to carry out checks to ensure their quality
and compatibility. Every time you make any
change to the system, carry out a careful check of
the functions, and check the effective range.
Don’t operate the system or the model if you are
not sure everything is working correctly; first lo-
cate the fault and eliminate it.
! Warning!
Radio-controlled models are not playthings in
the usual sense. Building these models, installing
the RC system, and operating them all demand
technical knowledge, due caution and a respon-
sible, safety-conscious approach. If you are neg-
ligent or make mistakes, the result may be seri-
ous damage and injury. As manufacturers, we
have no control over your methods of building
and operating any model, so all we can do is
point out these hazards expressly. We deny all li-
ability.
! A model, which is out of control, for whatever
reason, is capable of causing serious personal in-
jury and damage to property. It is essential that
you should take out suitable third-party insur-
ance, so that you are covered if, in spite of all
your care, an accident should occur.
! Always keep to the following sequence when
switching the equipment on and off, as this a-
voids the danger of an electric power system
bursting into life unexpectedly:
1. When switching on:
Transmitter ON first,
then receiver ON.
Connect flight battery and switch power system
ON
2. When switching off:
First disconnect flight battery and switch power
system OFF
Receiver OFF
Transmitter OFF
