© Munters AB, 2020 56
3. Enable Receive Outside Temp. Broadcast.
7.3 Ventilation Devices
•
Defining the Fans
•
Defining the Stir Fan
7.3.1 D
EFINING THE
F
ANS
The following sections detail how to configure fans.
NOTE
These settings should be configured by a technician familiar with the fan and inlet/curtain
specifications.
Fan air capacity defines how much air is provided when the fans run at full speed. These numbers are
used to calculate minimum air requirements.
In Defining the Preferences, page 95 define the measurement unit.
Define up to 20 relays or analog output ports as On/Off or 0 – 10 V fans, respectively
(refer to Mapping Devices, page 50).
•
On-Off Fans
•
0 – 10 Volt Fans
7.3.1.1 On-Off Fans
1. On the Device and Sensors screen, click a fan relay.
2. Click .
