Configuration/settings
User manual 55170_hdb_en_13 77 / 145
Notifications from the
device
Fig. 8-19: Processing of events of the "Notification" type
Processing of IO-Link events of the "Notification" type
Tab. 8-22: Processing of events of the "Notification" type
Property of the generated PROFINET process alarm:
User Structure Identifier (Format): 0x8320
Process alarm data
Selection Meaning
D = Default
Discard D IO-Link events of the "Notification" type are dis-
carded and are not forwarded.
Generating a process alarm For every "Notification" IO-Link event that is
sent by the IO-Link device, a PROFINET pro-
cess alarm is generated.
