Tab. 8-23: Process alarm data
Byte Meaning Value
0 Channel number MSB == 0x8000: No channel information available
!= 0x8000: Channel number (only for parameteriza-
tion of the extended integration of the Murrelektronik
IO-Link)
1LSB
2 Channel properties MSB 0x0000
3LSB
4 Reason for alarm MSB 0x9500: IO-Link event code 0x0000 (0) - 0x7FFF
(32767)
0x9501: IO-Link event code 0x8000 (32768) -
0xFFFF (65535)
5LSB
6 Reason for alarm
extended
MSB With reason for alarm 0x9500: IO-Link event code
With reason for alarm 0x9501: IO-Link event code
minus 0x8000 (32768)
7LSB
8 Reason for alarm
Additional value
MSB 0x00000000
9
10
11 LSB
