4 Introduction
4.1 Introduction to the EasyOne Air spirometer
4.1.1 Overview of EasyOne Air
The EasyOne Air spirometer
 Top-view of EasyOne Air
 Bottom-view of EasyOne Air
A EasyOne Flow Tube holder B Touchscreen
C Handles D Power button
A Speaker B USB port to connect to the cradle
C Lock screw for battery compartment D Battery compartment
A
B
D
C
C
A
C
D
B
