“Confidential, Do Not Duplicate without written authorization from NEC.”
5-11
SERVICE MODE
d) Max Watt
A proper value is set up when the lamp bulb is used above the typical wattage.
Use of the lamp bulb above the typical wattage should be done for user’s self-responsibility in all respects.
The lamp’s life may expire or the lamp may be ruptured.
Example of display
Entry Name
Max Watt
Typ7.00[kW] (*)
[ 6.00 [kW] ]
First line : Indication of Entry Name being edited
Second line : Indication of "Max Watt"
Third line : Indication of Typical Watt and Current setup
Fourth line : Indication of Wattage value, Input (*1)
(*1) 6.00
Enter numerical inputs by ↑ cursor movement.
Initial display is "0.00".
* It is necessary to enter Typical Watt in the first place.
Input range: Typical Watt <= Max Watt <= 9.99 [kW]
* It is OK even though no Max Watt input is entered.
Indication at that time: "-,--"
*To clear any input after the input has once been defined:
Enter "0.00".
