ASSEMBLY DIAGRAM
Diagram symbol Circuit symbol Part name Part code Q’ty Remarks
PRT1 BRACKET(HEAT SINK) 24H59951 1
PRT2 HEAT SINK(EB146-100) 24H56601 1
SRW023 PL-CPIMS*4*10*3KF 24V00461 3 Torque check
HEAT SINK
PRT1
PRT2
1 Attach HEAT SINK on BRACKET(HEATSINK).
SRW023 X3P
To Next Page
