ASSEMBLY DIAGRAM
MT Rear & Shield
Diagram symbol Circuit symbol Part name Part code Q’ty Remarks
PRT1 Rear Panel T Sassy 82N94321 1
1 Install the Rear Panel T Sassy.
After the installation, make key locking.
PRT1
Caution : External parts shall be handled carefully so that they are not damaged.
To Next Page
