ASSEMBLY DIAGRAM
Diagram symbol Circuit symbol Part name Part code Q’ty Remarks
PRT1 SIDE PANEL RR ASSY 24PS5301 1
PRT2 GASKET(STG2-10) 24C06051 300mm
PRT3 INSTRUCTION NAME PLATE 24L63652
Torque check
Torque check
Side Panel RR Sassy
1 Cut the Gasket (STG2-10) into a piece of 300mm and stick it to the Side Panel RR Assy.
PRT2
PRT1
Caution : External parts shall be handled carefully so that they are not damaged.
Caution : EMI (Electromagnetic Interference: Radio interference noise)
Do not forget adhesion of the NAME PLATE and the CAUTION LABEL
(Requirements of Safety Standard)
Confirm that all the safety standard requirements are printed on the
NAME PLATE
Confirm the factory certificate number on the NAME PLATE.
(North America)
(720SS) for SSS China
* For the INSTRUCTIOn NAME PLATE, adjust the upper part of the LABEL to
the extended line from the upper end of the Rear Panel B Assy.
On the side surface, stick the label 10 ~ 20mm from the end line of the Side
Panel RR Assy.
To be stuck to the front surface of the Side Panel RR Assy.
SAFETY
SAFETY
SAFETY
(Requirements of Safety Standard)
(Requirements of Safety Standard)
