ASSEMBLY DIAGRAM
Diagram symbol Circuit symbol Part name Part code Q’ty Remarks
PRT1 FRONT PANEL E 24D14171 1
PRT2 SRW069 SPECIAL SCREW(M4*18) 24N08431 2
Front Panel E Sassy
PRT2 X 2P
1 Mount the Special Screw (M4*8) on the Front Panel E.
Caution : External parts shall be handled carefully so that they are not damaged.
