PROGRAMMING
NESS D8 (V4.7) CONTROL PANEL – INSTALLER MANUAL
P47E, P48E
DESCRIPTION:
Area 1 User Codes
PROGRAM MODE LEVEL:
Installer, Remote by PC
FACTORY DEFAULT:
All User Codes assigned to Area 1
ASSIGNING USER CODES TO AREAS
Assign (or remove) User Codes to Areas.
PROGRAMMING SEQUENCE:
P47E 1E–8E toggles the options ON and OFF
Assigns User Codes 1–8 to AREA1
P48E 1E–7E toggles the options ON and OFF
Assigns User Codes 9–15 to AREA1
P49E 1E–8E toggles the options ON and OFF
Assigns User Codes 1–8 to AREA2
P50E 1E–7E toggles the options ON and OFF
Assigns User Codes 9–15 to AREA2
EXAMPLE:
To assign User Codes 1–8 to AREA1 and User Codes 9–15 to AREA2.
P47E turn ON lights 1–8
P48E turn OFF lights 1–7
P49E turn OFF lights 1–8
P50E turn ON lights 1–7
P49E, P50E
DESCRIPTION:
Area 2 User Codes
PROGRAM MODE LEVEL:
Installer, Remote by PC
FACTORY DEFAULT:
User Code 1 (Master Code) assigned to
Area 2.
NOTES:
• User Codes can be assigned to either a
single Area or to both Areas.
• If a User Code is assigned to NO Areas,
the code is effectively disabled and will
not operate the panel.
• To make a User Code arm or disarm just
one Area, assign that code only to the
required Area.
• Assigning User Codes to Areas has no
effect unless zones are also assigned to
Areas.
• For this option [Zone No] E toggles the
selection ON and OFF.
EXAMPLE:
User codes 1–8 are
assigned to AREA 1.
EXAMPLE:
User codes 9–15 are
assigned to AREA 2.
ON = Factory default setting.
OPTION No OPTION NoDESCRIPTION DESCRIPTION
P47E P48ECodes 1-8 to AREA1 Codes 9-15 to AREA1ON ONON ONON ONON ONONON ONON ON
ON
ON ON
P49E P50ECodes 1-8 to AREA2 Codes 9-15 to AREA2
1E User Code 1
1E User Code 9
2E User Code 2
2E User Code 10
3E User Code 3
3E User Code 11
4E User Code 4
4E User Code 12
5E User Code 5
5E User Code 13
6E User Code 6
6E User Code 14
7E User Code 7
7E User Code 15
8E User Code 8
User Codes
User Codes
2345678
1
P47E User Codes 1-8
P49E User Codes 1-8
P48E User Codes 9-15
P50E User Codes 9-15
2345678
1
9101112131415
9101112131415
AREA 1
AREA 2
