Virtual Private Networking
116
N600 Wireless Dual Band Gigabit VDSL2 Modem Router DGND3800B
The VPN Wizard Summary screen displays:
To view the VPNC-recommended authentication and encryption settings used by the
VPN Wizard, click the here link.
5. Click Done on the Summary screen.
The VPN Policies screen displays, showing that the new tunnel is enabled.
Note: See Use Auto Policy to Configure VPN Tunnels on page 124 for
information about how to enable the IKE keep-alive capability on an
existing VPN tunnel.
6. Repeat these steps for the gateway o
n LAN B, and pay special attention to the following
network settings:
• WAN IP of the remote VPN gateway (for example, 14.15.16.17)
• LAN IP settings of the remote VPN gateway:
- IP address (for example, 192.168.0.1)
- Subnet mask (for example, 255.255.255.0)
- Pre-shared key (for example, 12345678)
7. Use the VPN Status screen to activate the VPN tunnel by performing the following steps:
