Instead, if you are connected to same network as the AP, enter the LAN IP address
that is assigned to the AP. For information about finding the IP address, see Find the
IP address of the AP when you cannot use aplogin.net on page 24.
A login window displays.
3. Enter the AP local device password.
The local device password is the one that you specified. The local device password
is case-sensitive.
The Home page displays.
4. Select Administration > Logs.
The Logs page displays. The page shows the current time and, for each log entry,
the following information:
•
Action. The action that occurred, such as whether a WLAN connection was made.
•
Source. The name, IP address, or MAC address of a device, if applicable.
•
Date and time. The date and time that the entry was logged.
5.
To refresh the log screen, click the Refresh button.
6. To clear the log entries, click the Clear Log button.
User Manual67Manage the AP and Monitor the
Traffic
802.11ac Wireless Access Point Model WAC104
