interface.
Figure 2-73 Manage Log Interface
Table 2-44 Log Management Configuration Parameters
Name
Description
Download log
Log level
Select the log file level of gateway, the default is 4. The higher the level the more details the
log file will be.
Note: To avoid reducing the system performance, log level should be set to 4 or lower when
gateway is used in normal operation.
Syslog
System log server
The syslog server receives the logs that are otherwise recorded in debug.log, message.log and
boot.log.
Call message server
The syslog server receives the logs that are otherwise recorded in message.log.
Local port for
sending logs
The port used to send logs.
Procedure for downloading the log:
Step 1
Click
Download
, the gateway begins to assemble the logs.
Step 2
After a few seconds, the interface of log saving will appear.
