MX Series Voice Gateway User Manual
New Rock Technologies, Inc. 81
Name
Description
Timer E
non-INVITE request retransmit interval, UDP only. It is 500 ms by default.
Timer F
non-INVITE transaction timeout timer. It is 17000 ms by default and ranges from 2000 to 32000
ms.
Timer G
INVITE response retransmit interval. It is 2000 ms by default.
Timer H
Wait time for ACK receipt. It is 16000 ms by default.
Timer I
Wait time for ACK retransmits. It is 5000 ms by default.
Timer J
Wait time for non-INVITE request retransmission. It is 16000 ms by default.
Timer K
Wait time for response retransmission. It is 5000 ms by default.
URI RFC 3966
Calling party
number
Select the address scheme for calling party:
 SIP: SIP URI is used, for example
“From: <sip:212@172.16.10.126>;tag=143349062153-1”.
 TEL: tel URL is used, such as “From: <tel:212>;tag=143349065857-1”.
Called party number
Select the address scheme for called party:
 SIP: SIP URI is used, for example “To: <sip:212@172.16.10.126>”.
 TEL: tel URI is used, for example “To: <tel:212>”.
user=phone
Parameter
Places the user=phone field in front of the SIP version in the INVITE request.
e.g. INVITE sip:212@172.16.10.126;user=phone SIP/2.0
TCP
This parameter is only available on the OCS gateway (for example, the MX8A-OCS).
Protocol type
Select SIP/TCP or SIP/UDP, and the default is UDP. Note: both peers must choose the same
transmission type.
Local TCP port
Specify the local port used by SIP/TCP.
2.6.7 RADIUS (Unavailable on the HX4E)
After login, click Advanced >RADIUS to open this interface.
Figure 2-50 RADIUS Configuration Interface
