EDH0170FE1010 – 09/98 2
LDS1000 Controller for Laser Diode Sensors
2.1 Equipment
The LDS1000 electronic controller is delivered with:
A RS-232-C lead.
The present user’s manual.
The LDS-TOOLS Software.
A connection cable (5 or 10 meters, depending on the order).
As well as the extra accessories and options that may be ordered.
The sensor is delivered in a protection case which contains:
The optical head.
The control certificate.
The present user’s manual.
2.2 Modes of Operation
2.2.1 Manual Mode
The LDS1000 Controller displays angular rotation values of the mirror on a
frontal display screen. The operator uses the display and the active but-
tons on the front panel to:
Read the measurements.
Modify the integration constant.
Define the zero point.
Program the parameters of the connected sensor.
Modify the communication parameters (RS-232-C or IEEE-488).
Activate the analog outputs where available.
Refer to the chapter entitled: “Off-line use”.
