EDH0170FE1010 – 09/98 6
LDS1000 Controller for Laser Diode Sensors
4.0 Specification
The LDS1000 Controller can be used in conjunction with various optical
heads.. The dependent characteristics of the optical head are given in the
individual manuals.
The measurement results can only take on their full meaning in relation to
a unit that represents the value to be measured (distance, angle…). The
controller enables the result to be displayed on the unit that corresponds
to the sensor used.
4.1 General Characteristics
4.1.1 LDS-Vector Optical Head (example of Sensor)
•Wavelength 670 nm
•Peak power 900 µW
•Modulation 10 kHz
•Beam diameter 31 mm
•Beam direction <0.5 mrad in relation with autocollimator body
•Equivalent focal length 280 mm
•Beam divergence 0.1 mrad
•Ocular field ±15 mrad
•Measurement range ±2000 µrad
•Weight 1.065 kg
4.1.2 LDS1000 Controller
•Microprocessor 68000 (32 bits - 16 MHz)
•Display 2
x20 characters, adjustable brightness
•Interfaces RS-232-C and IEEE-488
•Measurement memory 2048 spots or
14336 spots depending on the option
•Analog output Available as an option
•TTL TRIGG input Measurement synchronization
•TTL PWOK output Beam signal
•Power supply 90/264 VAC, 50/60 Hz
•Consumption 30 VA
4.1.3 Measurements
•Digital resolution 0.1 µrad
•Measurement range ±2000 µrad
•Measurement error ±(1 ±0.02
xmeasurement.) µrad (i.e. ±2%)
•Max. measuring noise 0.02 µrad/√Hz
•Sampling frequency 2000 Hz
•Digital integration from 0.5 msec to 1 sec
